100M Ethernet Signal Slip Ring with RJ45 Connectors and electrical collector

Overview

Basic Info.

Model NO.	ECN000-04P3-10S-01EM
External Diameter	Ø70mm
Operating speed	0~300rpm
IP protection grade	IP54
Insulation Resistance	≥500MΩ@500VDC ≥300MΩ@100VDC
Contact material	Precious Metal
Electrical Noise	70mΩ (50rpm)
Rating Voltage	380VAC/VDC
Dielectric Strength	≥[email protected] (P) ≥[email protected] (S)
Circuit & Current	4*15A; 10*2A; 1*100M Ethernet
Transport Package	Carton Box
Specification	Precious metal / Alloy / Engineer plastic
Trademark	CENO
Origin	Shen Zhen, China
Production Capacity	50000pieces/Year

Product Description

Hollow shaft Ethernet slip rings provide 100Base-T or 1000Base-T Ethernet connections with a combination of 2&15 amp power connections,with advantages of reliable transmitting,no package loss,no cross talk,low loss, low electrical noise and Ethernet cables terminated with RJ45 connectors. We have over than 5000 designs, for more information about how CENO slip ring can fit your specific applications, please contact us.

Features

1. RJ45 connector for direct plug-and-play standard
2. High performance contact technology,smooth rotation
3. Available with multiple Ethernet channel, power and signal combinations

Applications

1. CCTV IP-surveillance
2. 100 / 1000BaseT transmission
3. Amusement equipment

Optional

1. Ethernet cable type
2. Circuit number
3. Current rating
4. Housing material

Product Parameters

ECN000-04P3-10S-01EM	Specification
Current	4*15A,10*2A,1*100M Ethernet
Voltage	0~380VAC/VDC
Electrical noise	≤70mΩ(50rpm)
Dielectric strength	≥[email protected](power)≥[email protected](signal)
Insulation resistance	≥500MΩ@500VDC(power)≥[email protected](signal)
Operating speed	0-300 rpm
Contact material	precious metals
Operating temperature	-20~+60ºC
Housing material	aluminum alloy
IP protection grade	IP54

Outline drawing
