Fiber optic rotary joint for continuous oil filling truck ( single & multi mode )
Overview ECN000-03F is a fiber optic slip ring from CENO electrical company, there are 2 circuits of multi mode signal w;
Overview
Features
Basic Info.
| Model NO. | ECN000-03F |
| Interface type | SC |
| Return loss, min | >20dB |
| Insert loss WOW | <1.5dB |
| Working humidity | <60% |
| Working temperature | -20°C~+80°C |
| Contact material | Precious metal |
| Housing material | Aluminum alloy + Stainless steel |
| Transport Package | Carton Box |
| Specification | Precious metal / Alloy / Engineer plastic |
| Trademark | CENO |
| Origin | Shen Zhen, China |
| Production Capacity | 50000pieces/Year |
Product Description
ECN000-03F is a fiber optic slip ring from CENO electrical company, there are 2 circuits of multi mode signal with the wave length from 850nm to 1310nm, and 1 circuit of single mode with the wave length from 1310nm to 1550nm in this fiber optic model. The interface type is SC and the fiber type is Armour optical fiber with external diameter Ø3.0mmin both single mode and multi mode. The protect grade is IP66 and is optional as customer's request.
Features
- Easy to integrate power or other signals
- High protect grade
- Low insert loss & low electric noise
- Continuous oil filling truck
- Medical equipment
- Rotary lamp box
- Medium of communication
- Fiber channel number
- Fiber type & interface type
- Protection grade
- Working speed
Product Parameters
| ECN000-03F | Specification | |
| Lead wire length | Rotor : 2000mm±20mmStator :2000mm±20mm | |
| Operating speed | 0~50rpm | |
| Contact material | Precious metal | |
| Housing material | Aluminum alloy + Stainless steel | |
| Working temperature | -20°C~+80°C | |
| Working humidity | <60% | |
| Protect grade | IP66 | |
| External diameter | Ø115±7 | |
| Fiber Parameter | ||
| Fiber mode | 1 * single mode | 2 * multi mode |
| Fiber type | Armour optical fiber with external diameter Ø3.0mm | Armour optical fiber with external diameter Ø3.0mm |
| Wave length | 1310 / 1550nm | 850 / 1310nm |
| Insert loss | <3.5dB | <3.5dB |
| Insert loss WOW | <1.5dB | <1.5dB |
| Return loss, min | >20dB | >20dB |
| Optical power, max | 23dBm | 23dBm |
| Interface type | SC | SC |
Outline drawing
